Case Report
Open Access
Subcapsular Hematoma of the Spleen in acute sever
pancreatitis unusual complication
Saleh Alzahrani*
King Abdulaziz Medical City National Guard Hospital -Riyadh
*Corresponding author:Saleh Alzahrani, King Abdulaziz Medical City National Guard Hospital –Riyadh, Tel. no: 96604378613; E-mail:
@
Received: 09 October, 2016; Accepted: 01 November , 2016; Published:10 November, 2016
Citation: Alzahrani S (2016) Subcapsular Hematoma of the Spleen in acute sever pancreatitis unusual complication. SOJ Surgery
3(3): 1-4. DOI: http://dx.doi.org/10.15226/2376-4570/3/3/00132
Abstract
The splenic complications of acute or chronic pancreatitis are
very rare. Splenic subcapsular hematoma is one of the rarest sequel of
pancreatitis. There are few cases reported with variable presentation
and management.
Here, we report an interesting case of subcapsular splenic hematoma in patient with sever pancreatitis which was managed none operatively by percutaneous drainage also an interesting intraoperative finding of cholecystentric fistula was identified which was managed by laparoscopy.
Conclusion: Splenic subcapsular hematoma is one of the rare complication of sever pancreatitis. Pecutanous drainage of subcapsular splenic hematoma appears to be less invasive and obviate splenectomy in stable patient.
Keywords: Subcapsular hematoma of the spleen; Unusual complication of pancreatitis; Percutaneous drainage; Hematoma; Laparoscopy; Case report
Here, we report an interesting case of subcapsular splenic hematoma in patient with sever pancreatitis which was managed none operatively by percutaneous drainage also an interesting intraoperative finding of cholecystentric fistula was identified which was managed by laparoscopy.
Conclusion: Splenic subcapsular hematoma is one of the rare complication of sever pancreatitis. Pecutanous drainage of subcapsular splenic hematoma appears to be less invasive and obviate splenectomy in stable patient.
Keywords: Subcapsular hematoma of the spleen; Unusual complication of pancreatitis; Percutaneous drainage; Hematoma; Laparoscopy; Case report
Introduction
Subcapsular hematoma of the spleen is a rare complication
of acute or chronic pancreatitis [2–6]. It includes splenic vein
thrombosis, arterial pseudoaneurysm, subcapsular splenic
hematoma, and splenic rupture [1, 9, 16, 17]. The management
of this complication remains controversial. Thompson and
Ashley [8] advocated early splenectomy to prevent rupture of
the splenic hematoma and its associated morbidity. Rypens
et al [7] suggested that most of these complications could
potentially regress and be managed conservatively. In addition,
percutaneous drainage of the subcapsular splenic hematoma
has been demonstrated in 3 case reports in the literature [1, 9,
10]. We here present a case of a subcapsular splenic hematoma
complicating acute sever necrotizing pancreatitis with symptoms
of abdominal pain and frequent vomiting. The splenic hematoma
was diagnosed in follow up computer tomography (CT) for
necrotizing pancreatitis and it was treated successfully with
ultrasound-guided percutaneous drainage.
Case report
71 year old Saudi women known to have hypertension controlled with medication presented to emergency
department with complain of one week abdominal pain,
vomiting and anorexia. Two weeks prior to her presentation
she was hospitalize in periphery hospital with diagnosis of
pancreatitis. She was managed conservatively at surgical ward
and discharge in stable condition. She was planned for interval
cholecystectomy. At her presentation she wasn’t able to take
orally with frequent vomiting. She had abdominal pain mainly
at epigastric area intermittent with radiation to the back. She
had no fever, jaundice, nor change of bowel habit. She had no
history of trauma or previous interventions. There was no
history of use of anticoagulation. She had no previous surgery.
Other systemic review was unremarkable. Clinical examination
showed elderly women comfortable in bed not in distress. Her
vital sign was stable. The abdominal examination showed mild
tenderness at epigastric area. She had leuckocytosis of 17,
hemoglobin of 96. Liver function test was normal except mild
indirect hyper bilirubinemia which was normalizing in follow
up labs her amylase was normal. Abdominal ultrasound showed
thick gallbladder wall with gallstone. There was no dilatation of
common bile duct or intra hepatic ducts. CT abdomens showed
sign of sever necrotizing pancreatitis with multiple pancreatic
tail pseudocyst [Figure1]. She was diagnosed with complicated
sever necrotizing pancreatitis. She was managed conservatively.
Follow up C.T in 2 weeks period done for her persistent symptoms
which showed large sub-capsular hematoma of spleen. The size
was 13 *6 * 10 cm [Figure2]. Ultrasound guided drainage done
for the hematoma. Post drainage patient was kept in monitor bed
till output was serous in color follow up C.T showed complete
resolution. During laparoscopic cholecystectomy, there was
an intra-operative finding of adhesion and cholecystentric
fistula [Figure3]. The fistula was taken down and repaired with
intracorporal PDS suture after removal of the stone [Figure 4, 5].
Post operatively was uneventful follow up C.T after a month from
discharge showed no recurrence [Figure 6].
Discussion
The pancreatic tail is close to the hilum of the spleen.
This anatomy provides a potential for splenic involvement in pancreatitis [3–6, 11, 12]. Splenic complications associated
with pancreatitis include splenic vein thrombosis, arterial
pseudoaneurysms, splenic hematoma and splenic rupture [1–7].
These complications occur in 1–5% of pancreatitis.6 They may
occur through one of the following mechanisms:(1) splenic
vessel complications, such as thrombosis and pseudoaneurysm
formation; (2) dissection of a pancreatic pseudocyst into the hilum
of the spleen, which can cause splenic rupture, splenic infarction,
Figure 1: Sings of sever necrotizing pancreatitis, Multiple pseudocysts,
Moderated ascites. Spleen is normal.
Figure 2: Large subcapsular splenic hematoma compressing (star)
Figure 3: Intraoperative findings. Cholecystentric fistula.(star)showed
stone impaction
Figure 4,5: Intraoperative findings. Cholecystentric fistula.(star)showed
stone impaction
Figure6: Follow up CT showed complete resolution with no recurrence.
arterial hemorrhage, or venous thrombosis; or (3) extension of
the inflammatory process from the tail of the pancreas into the
hilum of the spleen, which may induce hematoma formation
[3–7]. Splenic hematoma is a rare complication of acute or
chronic pancreatitis when compared with traumatic origin of
subcapsular hematoma. In a recent large series of 500 patients
with chronic pancreatitis, an estimated prevalence of 0.4% was
reported [2]. Local factors (thrombosis of the splenic artery
or veins, intrasplenic pseudocysts, perisplenic adhesions,
enzymatic digestion) and coagulation disorders may play a role
in the pathogenesis of splenic hematoma [3,4,7,8]. The splenic
hematoma in this case was probably caused by the erosion of
cystic pancreatic inflammation from the tail of the pancreas into
the hilum of the spleen as demonstrated on initial abdominal CT
[Figure1]. The hematoma is contained within the splenic capsule
[Figure2]. The delayed presentation of the hematoma makes this
theory most probably. Extension of pancreatic pseudocyst to subcapsule
of the spleen (intra-splenic pseudocyst) was initially our
thought but C.T density as well the output later was consistent
with hematoma. Amylase level from drained fluid was not high
as well. Because splenic involvement in patients with acute or
chronic pancreatitis is uncommon, the diagnosis of subcapsular
hematoma of the spleen needs the alertness of physicians and
imaging studies. Patients with pancreatitis exhibiting a mass
in the left upper quadrant, pain radiating to the left shoulder,
elevation of the left diaphragm, and persistent symptoms despite
normal laboratory results should be suspected to have splenic
complications. Abdominal CT should be performed early in
questionable patients. A splenic hematoma can be distinguished
from simple fluid collection based on density (Hounsfield units
> 30). It was 45 unit in our case. Angiography is not essential
for the diagnosis, but would be indicated if splenic artery
pseudoaneurysm, splenic vein thrombosis or active bleeding
was suspected [8,13]. The management of subcapsular splenic
hematoma in pancreatitis remains controversial [11]. Surgical
treatment with splenectomy, percutaneous drainage, and
observation are management options. Kuramitsu et al [12]
reported 1 case with chronic pancreatitis and a large subcapsular
splenic hematoma (10 × 10 cm). After conservative management
for 6 weeks, the size of the hematoma had not change; rupture
of the hematoma with peritonitis occurred after a relapse
of pancreatitis, which prompted surgical intervention [13]. They suggested that in cases of large splenic hematoma (> 5
cm) as a complication of pancreatitis, pressure reduction by
percutaneous drainage or laparotomy should be administered
as early as possible. Some reports have advocated aggressive
management with early splenectomy to avoid splenic rupture
[2, 8, 14]. Thompson and Ashley [8] described 3 cases with
acute pancreatitis accompanied by large subcapsular hematoma
of the spleen. Two patients recovered after splenectomy, but 1
patient died due to continuing blood loss. They suggested that
the treatment of subcapsular splenic hematoma should be a
splenectomy in the vast majority of patients to prevent continuing
blood loss and potential rupture [8].
Percutaneous drainage for splenic subcapsular collections may be a feasible treatment, but there are only a few reports of it in the literature. Quinn et al [15] reported 2 cases of intrasplenic pseudocysts due to pancreatitis and 2 cases of traumatic splenic hematoma undergoing percutaneous drainage. Vyborny et al [10] were the first to demonstrate successful ultrasound-guided percutaneous drainage of a large subcapsular hematoma of the spleen complicating pancreatitis. Siu [9] described 1 case of spontaneous subcapsular hematoma of the spleen (13 × 8 × 5 cm) complicating chronic pancreatitis that was treated by CTguided percutaneous drainage. Both reports showed that the benefits of percutaneous drainage of a splenic hematoma include prompt relief of symptoms, short recovery time, avoidance of splenic rupture and, most importantly, spleen preservation [9,10]. No complication was noted after the procedure. The patients remained asymptomatic at 2 and 0.5 years of followup, respectively [9,10]. Dr. Chun-Chia did grate review of non invasive drainage of subcapsular hematoma and he reports one case with successful ultrasound guided drainage [1]. Our patient is the fourth documented case of successful percutaneous drainage of a large subcapsular splenic hematoma complicating pancreatitis.
Rypens et al [7] reviewed 16 patients with splenic parenchymal complications of acute or chronic pancreatitis. Subcapsular splenic collections were detected in 11 patients. Two patients underwent emergency splenectomy, 2 patients received delayed splenectomy, and the others were treated conservatively. Time for healing of splenic lesions varied from 1 week to 4 months [7]. The authors suggested that most splenic complications of pancreatitis regress spontaneously and may be managed conservatively. Surgical indication is based on clinical findings. Patel et al [16] reported a case of large subcapsular splenic hematoma (11.1×9.5 cm) resulting from pancreatitis that was managed conservatively with a good outcome. A CT scan performed 4 months later showed marked resolution of the hematoma. They suggested that it is appropriate to manage splenic subcapsular hematoma conservatively in a hemodynamically stable patient who is showing improving symptoms and signs [16].
In our case there was another challenge, which was intraoperative cholecystoentric fistula Figure3,4, 5. Cholecystoentric fistula are a rare complication of gallstone disease, with a reported incidence of 3–5% in patients with cholelithiasis1 and 0.15–4.8% in patients undergoing biliary surgery [19-22]. The exact etiology of such fistulation is yet to clearly established. According to Glenn et al. [5] following stone formation in the gallbladder, an acute inflammatory process with obstruction of the cystic duct results in adhesion of the gallbladder to the contiguous viscus, usually duodenum. Recurrent episodes of such inflammation result in the destruction of the wall of the gallbladder and the adjacent viscus, ultimately resulting in erosion of the tissues and fistulation. According to an alternate theory, the mechanical pressure due to a gallstone results in erosion of the tissues in the gallbladder wall with necrosis until a fistula forms with the contiguous viscus [6]. Endostapling device to transect the fistula was the preferred management in multiple articles [18]. We could not apply this to our patient because of presence of stone impaction in fistula Figure 5. cholecystofistulectomy was mandatory in our case to retrieve large stone. A stapled transaction of the fistula may be the procedure of choice to avoid contamination of the peritoneal cavity in case there was no stone impaction [18]. Laparoscopic intracorporal suturing was the closure method in our case.
Percutaneous drainage for splenic subcapsular collections may be a feasible treatment, but there are only a few reports of it in the literature. Quinn et al [15] reported 2 cases of intrasplenic pseudocysts due to pancreatitis and 2 cases of traumatic splenic hematoma undergoing percutaneous drainage. Vyborny et al [10] were the first to demonstrate successful ultrasound-guided percutaneous drainage of a large subcapsular hematoma of the spleen complicating pancreatitis. Siu [9] described 1 case of spontaneous subcapsular hematoma of the spleen (13 × 8 × 5 cm) complicating chronic pancreatitis that was treated by CTguided percutaneous drainage. Both reports showed that the benefits of percutaneous drainage of a splenic hematoma include prompt relief of symptoms, short recovery time, avoidance of splenic rupture and, most importantly, spleen preservation [9,10]. No complication was noted after the procedure. The patients remained asymptomatic at 2 and 0.5 years of followup, respectively [9,10]. Dr. Chun-Chia did grate review of non invasive drainage of subcapsular hematoma and he reports one case with successful ultrasound guided drainage [1]. Our patient is the fourth documented case of successful percutaneous drainage of a large subcapsular splenic hematoma complicating pancreatitis.
Rypens et al [7] reviewed 16 patients with splenic parenchymal complications of acute or chronic pancreatitis. Subcapsular splenic collections were detected in 11 patients. Two patients underwent emergency splenectomy, 2 patients received delayed splenectomy, and the others were treated conservatively. Time for healing of splenic lesions varied from 1 week to 4 months [7]. The authors suggested that most splenic complications of pancreatitis regress spontaneously and may be managed conservatively. Surgical indication is based on clinical findings. Patel et al [16] reported a case of large subcapsular splenic hematoma (11.1×9.5 cm) resulting from pancreatitis that was managed conservatively with a good outcome. A CT scan performed 4 months later showed marked resolution of the hematoma. They suggested that it is appropriate to manage splenic subcapsular hematoma conservatively in a hemodynamically stable patient who is showing improving symptoms and signs [16].
In our case there was another challenge, which was intraoperative cholecystoentric fistula Figure3,4, 5. Cholecystoentric fistula are a rare complication of gallstone disease, with a reported incidence of 3–5% in patients with cholelithiasis1 and 0.15–4.8% in patients undergoing biliary surgery [19-22]. The exact etiology of such fistulation is yet to clearly established. According to Glenn et al. [5] following stone formation in the gallbladder, an acute inflammatory process with obstruction of the cystic duct results in adhesion of the gallbladder to the contiguous viscus, usually duodenum. Recurrent episodes of such inflammation result in the destruction of the wall of the gallbladder and the adjacent viscus, ultimately resulting in erosion of the tissues and fistulation. According to an alternate theory, the mechanical pressure due to a gallstone results in erosion of the tissues in the gallbladder wall with necrosis until a fistula forms with the contiguous viscus [6]. Endostapling device to transect the fistula was the preferred management in multiple articles [18]. We could not apply this to our patient because of presence of stone impaction in fistula Figure 5. cholecystofistulectomy was mandatory in our case to retrieve large stone. A stapled transaction of the fistula may be the procedure of choice to avoid contamination of the peritoneal cavity in case there was no stone impaction [18]. Laparoscopic intracorporal suturing was the closure method in our case.
Conclusion
Splenic subcapsular hematoma is one of the rare complication
of sever pancreatitis. Pecutanous drainage of subcapsular splenic
hematoma appears to be less invasive and obviate splenectomy
in stable patient.
ReferencesTop
- Tseng CW, Chen CC, Chiang JH, Chang FY, Lin HC, Lee SD. Percutaneous drainage of large subcapsular hematoma of the spleen complicating acute pancreatitis. J Chin Med Assoc. 2008;71(2):92–95. doi: 10.1016/S1726-4901(08)70081-9.
- Malka D, Hammel P, Levy P, Sauvanet A, Ruszniewski P, Belghiti J, et al. Splenic complications in chronic pancreatitis: prevalence and risk factors in a medical–surgical series of 500 patients. Br J Surg. 1998;85(12):1645–9.
- Lankisch PG. The spleen in inflammatory pancreatic disease. Gastroenterology. 1990;98(2):509–16.
- Mauro MA, Schiebler ML, Parker LA, Jaques PF. The spleen and its vasculature in pancreatitis: CT findings. Am Surg. 1993;59(3):155–9.
- Calvo E, Ciguenza R, Alvarez-Sala JL, Massa B, Espinos D. Spontaneous rupture of the spleen in chronic pancreatitis: an often forgotten complication. Gastroenterol Clin Biol. 1992; 16(2):194.
- Fishman EK, Soyer P, Bliss DF, Bluemke DA, Devine N. Splenic involvement in pancreatitis: spectrum of CT findings. AJR Am J Roentgenol. 1995;164(3):631–5.
- Rypens F, Deviere J, Zalcman M, Braude P, Van de Stadt J, Struyven J, et al. Splenic parenchymal complications of pancreatitis: CT findings and natural history. J Comput Assist Tomogr. 1997;21(1):89–93.
- Thompson JE Jr, Ashley SW. Subcapsular hematoma of the spleen associated with acute pancreatitis. Surgery. 1997;121(2):231–233. doi:10.1016/S0039-6060(97)90297-X.
- Siu TL. Percutaneous drainage of spontaneous subcapsular haematoma of the spleen complicating chronic pancreatitis. Surgeon. 2004;2(1):52–55.
- Vyborny CJ, Merrill TN, Reda J, Geurkink RE, Smith SJ. Subacute subcapsular hematoma of the spleen complicating pancreatitis: successful percutaneous drainage. Radiology. 1988; 169(1):161–162.
- Chen LY, Shih HC, Wu JJ, Wen YS, Huang MS, Huang CI, et al. The role of diagnostic algorithms in the management of blunt splenic injury. J Chin Med Assoc. 2005;68(8):373–378.
- Jiang CF, Shiau YC, Ng KW, Tan SW. Serum interleukin-6, tumor necrosis factor-alpha and C-reactive protein in early prediction of severity of acute pancreatitis. J Chin Med Assoc. 2004; 67(9):422–6.
- Kuramitsu T, Komatsu M, Ono T, Nakajima K, Funaoka M, Kato J, et al. Ruptured subcapsular giant hematoma of the spleen as a complication of chronic pancreatitis. Intern Med. 1995;34:564–8.
- Agnifili A, Gianfelice F, Gola P, Guadagni S, Ibi I, Onorato A, et al. Subcapsular splenic hematoma complicating chronic relapsing pancreatitis. Case report. Eur J Surg. 1991;157(1):63–5.
- Quinn SF, van Sonnenberg E, Casola G, Wittich GR, Neff CC. Interventional radiology in the spleen. Radiology. 1986;161(2):289–91.
- Patel VG, Eltayeb OM, Zakaria M, Fortson JK, Weaver WL. Spontaneous subcapsular splenic hematoma: a rare complication of pancreatitis. Am Surg. 2005;71(12):1066–1069.
- Gandhi V, Philip S, Maydeo A, Doctor N. Ruptured subcapsular giant haematoma of the spleen–a rare complication of acute pancreatitis. Trop Gastroenterol. 2010;31:123–124.
- Chowbey PK, Bandyopadhyay SK, Sharma A, Khullar R, Soni V, Baijal M. Laparoscopic management of cholecystoenteric fistulas. J Laparoendosc Adv Surg Tech A. 2006 ;16(5):467-72.
- Haff RC, Wise L, Ballinger WF. Biliary enteric fistulas. Surg Gynecol Obstet. 1971;133(1):84–88.
- Ozdemer A, Atli MY, Coscun T, Ozenk A, Hensek E. Biliary enteric fistulas. Int Surg. 1997;82(3):280–283.
- Zuemer FC, Coffin-Kwart VE, Conway MJ. Biliary enteric fistulas: management of 47 cases in native Americans. Am J Surg. 1979;138(2):301–304.
- Glenn F, Reed C, Grafe WR. Biliary enteric fistula. Surg Gynecol Obstet. 1981;153(4):527-31.
